Swiss Tech Minimalism
- Grid-led alignment and explicit hierarchy
- High information density without visual noise
- Flat surfaces, precise rules and restrained radii
- Manrope headings, Inter UI and mono technical labels
Adaptive operations design system
Structured calm for work in motion.
A contract-ready system of foundations, recipes, fields, blocks and deliberate divergent interactions. 89 dynamic component types are catalogued below.
70Swiss technical
20Modular bento
10Blueprint flow
RequestDispatchField workAudit
/01
Theme composition
The ratio is an allocation of visual responsibility, not a percentage of pixels.
Modular / Bento Systems
- Composable blocks with unequal emphasis
- 1–3 column container-aware layouts
- Strong grouping through adjacency, not decoration
- Panels scale from operational rows to dashboards
Blueprint / Flow Graphics
- Measured grids, nodes and route lines
- Mint identifies active movement through indigo systems
- Animated only when it explains state or direction
- Static and reduced-motion equivalents are mandatory
/02
Colour primitives
Semantic pairs preserve meaning in light and dark modes; raw brand values are never used as status logic.
Kazi Indigo
#283C78Authority, primary actions, selected navigation
Flow Mint
#36D3A0Focus, live flow, success emphasis
Operational Ink
#111827Primary text and high-contrast structure
Cloud Surface
#F4F7FCCanvas and low-emphasis regions
Signal Blue
#315CCBInformation and active data
Amber
#A85A00At-risk and warning states
Critical Red
#A32929Failures, breaches and destructive actions
Service Green
#176B4DCompletion and healthy service states
/03
Typography
Product voice and interface density use separate families; technical metadata gets a third, deliberately narrow voice.
DisplayOperations in one flow48 / 52 · Manrope 600
H1Operations in one flow36 / 42 · Manrope 600
H2Operations in one flow28 / 34 · Manrope 600
H3Operations in one flow20 / 26 · Manrope 650
BodyOperations in one flow14 / 22 · Inter 400
LabelOperations in one flow12 / 16 · Inter 650
TechnicalOperations in one flow11 / 16 · JetBrains Mono 500
/04
Spacing, margins and geometry
A 4px base unit supports compact operational density while larger section margins protect comprehension.
Spacing scale
4px8px12px16px20px24px28px32px40px48px64px80pxPage margins
20 / 32 / 48px
Narrow, medium and wide viewport edges.
Content maximum
1560px
Dense authenticated surfaces; reading content is narrower.
Radii
8 / 14 / 24px
Controls, panels and rare large brand surfaces.
Borders
1px semantic line
Primary grouping mechanism; elevation is reserved for overlays.
Grid
12 columns / 20px gap
Blocks adapt by container, not device labels.
/05
Motion and microinteraction primitives
Motion is mechanical and explanatory: short travel, no ornamental bounce, and no dependency on animation for meaning.
Fast feedback
120–160ms
Press, hover, focus and selection response.
Block transition
240–380ms
Reveal, presence and local layout change.
Easing
[.22, 1, .36, 1]
Decisive deceleration without overshoot.
Reduced motion
0–1ms / static
Flow paths freeze; transforms and stagger disappear.
/06
Tier-0 primitives
Every primitive is clickable and opens a complete visual variant page.
Action primitives
01
Button
Variants and states
primarysecondaryquietdanger
Used in KaziLayer
Submits commands and triggers permitted actions.
View all 6 variants →02
IconButton
Variants and states
defaultselectednotificationloading
Used in KaziLayer
Compact toolbar, navigation and row actions with accessible names.
View all 5 variants →03
DropdownMenu
Variants and states
defaultgroupedcheckeddanger action
Used in KaziLayer
Holds lower-priority commands without hiding primary work.
View all 4 variants →Form primitives
01
Input
Contract validation and help appear here.
Variants and states
defaultfocusfillederror
Used in KaziLayer
Short text, numeric, contact and machine identifier entry.
View all 6 variants →02
Textarea
Contract validation and help appear here.
Variants and states
defaultfocusfillederror
Used in KaziLayer
Plain operational long text where formatting is not required.
View all 6 variants →03
Select
Contract validation and help appear here.
Variants and states
placeholderselectedopenerror
Used in KaziLayer
Finite contract-owned choices.
View all 5 variants →04
Combobox
Contract validation and help appear here.
Variants and states
emptysearchingresultsselected
Used in KaziLayer
Large or remote option sets and tenant-scoped relations.
View all 5 variants →05
MultiSelect
HVAC ×Priority ×
Variants and states
emptyselectedsearchingmax selected
Used in KaziLayer
Tags, scopes and multiple contract-owned values.
View all 5 variants →06
Checkbox
Variants and states
uncheckedcheckedindeterminateerror
Used in KaziLayer
Independent Boolean choice and bounded bulk selection.
View all 5 variants →Container primitives
01
Dialog
Dialog
Focused operational content
Variants and states
standardwideformloading
Used in KaziLayer
Focused modal tasks that must remain in context.
View all 4 variants →02
AlertDialog
AlertDialog
Focused operational content
Variants and states
confirmdestructivependingerror
Used in KaziLayer
High-consequence confirmation before a command.
View all 4 variants →03
Sheet
Sheet
Focused operational content
Variants and states
rightleftfull-heightform
Used in KaziLayer
Contextual detail, edit and scheduling tasks.
View all 4 variants →04
Drawer
Drawer
Focused operational content
Variants and states
bottomsnapfullmobile filter
Used in KaziLayer
Touch-friendly narrow-screen secondary surfaces.
View all 4 variants →05
Tabs
Tabs
Focused operational content
Variants and states
linecontainedcompactoverflow
Used in KaziLayer
Switches peer views without changing record meaning.
View all 4 variants →Data and feedback primitives
01
Badge
NeutralAt riskReady
Variants and states
neutralinfosuccesswarning
Used in KaziLayer
Compact labelled metadata and status reinforcement.
View all 6 variants →02
Avatar
AKBMLW+4
Amina added completion evidence.
Variants and states
imageinitialsonlineaway
Used in KaziLayer
People and collaboration identity.
View all 5 variants →03
Table
TableLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
comfortablecompactselectablesortable
Used in KaziLayer
Dense aligned operational comparisons.
View all 6 variants →04
ScrollArea
ScrollAreaLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
verticalhorizontalbothedge fade
Used in KaziLayer
Bounds overflow inside dense panels.
View all 4 variants →05
Separator
SeparatorLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
horizontalverticallabelled
Used in KaziLayer
Creates precise structural divisions.
View all 3 variants →06
Progress
Progress72%
VALIDATEPROCESSCOMPLETE
Variants and states
determinateindeterminatesuccesserror
Used in KaziLayer
Shows bounded job, upload and workflow completion.
View all 4 variants →07
Skeleton
Variants and states
textrowcardstat
Used in KaziLayer
Preserves the expected content shape while loading.
View all 5 variants →Layout primitives
01
Stack
1234
Variants and states
compactcomfortablespaciousrecursive
Used in KaziLayer
Vertical rhythm for fields, panels and sections.
View all 4 variants →02
Cluster
1234
Variants and states
startbetweencenterwrap
Used in KaziLayer
Groups actions, tags and compact metadata.
View all 4 variants →03
Split
1234
Variants and states
1:12:13:2stacked
Used in KaziLayer
Main and supporting regions that collapse by container.
View all 4 variants →/07
Dynamic component catalogue
Each component is grouped by dynamic type, followed by every documented variant/state and its KaziLayer placement.
Dynamic component type 01
Universal projected kernel
Contract metadata resolves content, policy and state; recipe axes resolve presentation.
01
Projection
ProjectionOperational record projection
ActiveVariants and states
context: list / detail / picker / dashboard / threadintent: row / card / detail / stat / media / relation / audit / threaddensity: compact / comfortable / spacioustone: neutral / info / success / warning / danger
Used in KaziLayer
Projects requests, work orders, people, places, assets, contracts, webhooks and audit records into reusable surfaces.
View all 5 variants →02
FieldView
FieldViewOperational record projection
ActiveVariants and states
compactcomfortablespaciousmedia
Used in KaziLayer
Displays typed values in rows, cards, detail views, dashboards and activity streams.
View all 5 variants →03
FieldInput
FieldInputOperational record projection
ActiveVariants and states
defaultfocuserrordisabled
Used in KaziLayer
Provides the accessible input context for every contract-supported widget.
View all 6 variants →04
FieldFilter
FieldFilterOperational record projection
ActiveVariants and states
inactiveactiveinvalidtyped operators
Used in KaziLayer
Used by request, work-order, audit, integration and search filter surfaces.
View all 4 variants →05
FieldDiff
FieldDiffOperational record projection
ActiveVariants and states
unchangedchangedconflictwidget before / after
Used in KaziLayer
Used in audit review, stale-record recovery and conflict-resolution experiences.
View all 4 variants →06
ProjectedForm
ProjectedFormOperational record projection
ActiveVariants and states
recipe: inline / sheet / stepper / authmode: create / edit / command / registrationediting / submitting / invalid / saved / error / conflict
Used in KaziLayer
Powers authentication, request intake, record editing, commands, contract administration and settings.
View all 3 variants →07
ListBlock
ListLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
intent: row / carddensity: compact / comfortable / spaciousnarrow: scroll / collapse / priorityloading / empty / error / stale / live / selected
Used in KaziLayer
Renders operational lists for core records, audit events, jobs, integrations and search.
View all 4 variants →08
DetailBlock
DetailLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
surface: flat / bordered / raised / insetfull-pagesheetcontainer-adaptive
Used in KaziLayer
Shows record, contract, webhook and audit detail without per-model page components.
View all 4 variants →09
StatsBlock
SLA within target93.4%
+2.8%Variants and states
density: comfortable / spacioustone by metric statesurface recipesloading / empty / error
Used in KaziLayer
Used for SLA, workload, capacity, queue health and operations-dashboard metrics.
View all 4 variants →10
ActivityBlock
ActivityLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
compactcomfortableevent-type filteringempty / loading / error
Used in KaziLayer
Displays work history, audit trails, contract publication and webhook delivery activity.
View all 4 variants →11
ActionBar
Variants and states
compactcomfortabletone from actionpending
Used in KaziLayer
Hosts permitted record and collection actions such as assign, schedule, publish, retry and export.
View all 6 variants →12
ActionMenu
Variants and states
inlineoverflowcompactcomfortable
Used in KaziLayer
Moves lower-priority permitted actions into accessible menus on dense rows and cards.
View all 5 variants →13
BulkActions
Variants and states
hiddenactiveexecutingcomplete
Used in KaziLayer
Supports bounded reassignment, tagging, export and state-transition selections.
View all 6 variants →14
ConfirmAction
This transition requires confirmation.
Variants and states
standarddestructiveconfirm-onlycommand-input
Used in KaziLayer
Guards archive, contract publication, bulk commands, secret rotation and transitions.
View all 5 variants →15
StatusBadge
StatusBadgeOperational record projection
ActiveVariants and states
tone: neutral / info / success / warning / dangerpilldotalways-visible label
Used in KaziLayer
Communicates workflow, SLA, contract, job, webhook and notification status.
View all 4 variants →16
AppNav
KAZILAYEROperations/App Nav
Variants and states
expandedcollapsedmobile-sheetgrouped
Used in KaziLayer
Provides the authenticated tenant navigation shell across operational modules.
View all 6 variants →17
Breadcrumbs
KAZILAYEROperations/Breadcrumbs
Variants and states
fullcompactcollapsedmetadata labels
Used in KaziLayer
Provides route and record context across list, detail, admin and narrow sheet surfaces.
View all 4 variants →18
CommandPalette
KAZILAYEROperations/Command Palette
Variants and states
closedopensearchingno-results
Used in KaziLayer
Supports cross-module navigation, global search and permitted collection commands.
View all 5 variants →19
EmptyState
No work matches this view
Adjust filters or create a permitted record.
Variants and states
no-datano-resultsno-relatedno-config
Used in KaziLayer
Explains empty operational and configuration surfaces without inventing unavailable actions.
View all 5 variants →20
ErrorState
Could not update assignment
Reload the current record and try again.
Variants and states
retryablenon-retryableconflictpermission
Used in KaziLayer
Provides honest failure states and safe recovery paths for API, policy and realtime failures.
View all 7 variants →21
LoadingState
Variants and states
skeletoninlineprogresslist / detail / stat / block
Used in KaziLayer
Matches loading feedback to the shape of the requested content or background work.
View all 4 variants →22
ToastFeedback
No work matches this view
Adjust filters or create a permitted record.
Variants and states
infosuccesswarningdanger
Used in KaziLayer
Reports mutation, upload, job, webhook and publication outcomes.
View all 6 variants →23
PageBlocks
PagesLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
listdetaildashboardauth
Used in KaziLayer
Builds pages from registered blocks while keeping route components thin.
View all 6 variants →24
HeaderBlock
HeaderLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
source: meta / record / explicitcompactstandarddescription / status / actions slots
Used in KaziLayer
Introduces every projected list, detail, dashboard and administration page.
View all 4 variants →25
FiltersBlock
FiltersLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
expandedcollapsedmobile-sheetactive / inactive
Used in KaziLayer
Filters operations, dispatch, search, audit, notifications and integrations.
View all 5 variants →26
RelatedBlock
RelatedLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
rowcardcompactcomfortable
Used in KaziLayer
Displays declared relationships between customers, sites, assets, technicians and work.
View all 5 variants →27
SplitBlock
SplitLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
main / aside ratiosstacked below thresholdgap / density tokens
Used in KaziLayer
Composes record detail with activity, comments, evidence or related information.
View all 3 variants →28
GridBlock
GridLIVE · 04
WO-2814
WO-2824
WO-2834
Variants and states
1 column2 columns3 columnscontainer-adaptive
Used in KaziLayer
Composes dashboards and administration overviews from registered child blocks.
View all 4 variants →29
ChatBlock
AKBMLW+4
Amina added completion evidence.
Variants and states
compactcomfortablepublicinternal
Used in KaziLayer
Projects policy-scoped comments and mentions on requests and work orders.
View all 5 variants →Dynamic component type 02
Dynamic field renderers
Every field knows its widget and context, never the business model name.
01
Field/text
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Names, titles, references, labels, addresses and short strings.
View all 5 variants →02
Field/textarea
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Operational reasons, incident notes, comments and failure descriptions.
View all 6 variants →03
Field/richtext
Contract validation and help appear here.
Variants and states
compact / full viewinputdifffocus / error / disabled / over-limit
Used in KaziLayer
Only explicitly designated sanitized WYSIWYG fields with plain-text projection.
View all 4 variants →04
Field/markdown
## Completion notes
Variants and states
rendered / sourceinputdiffediting / preview / error / over-limit
Used in KaziLayer
Handover, runbook and documentation content.
View all 4 variants →05
Field/email
Contract validation and help appear here.
Variants and states
viewinputfiltervalid / invalid / disabled
Used in KaziLayer
Invitations, contacts, notification targets and account settings.
View all 5 variants →06
Field/phone
Contract validation and help appear here.
Variants and states
viewinputfiltervalid / invalid / disabled
Used in KaziLayer
Customer contacts and phone notification destinations.
View all 4 variants →07
Field/secret
••••••••••••
Variants and states
inputmasked viewrotateempty / set / revealed-once / invalid / rotating
Used in KaziLayer
Passwords, webhook secrets and integration credentials without revealing stored secrets.
View all 4 variants →08
Field/select
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Finite contract-owned choices such as urgency, role, visibility and event type.
View all 5 variants →09
Field/status
ScheduledAt riskComplete
Variants and states
viewfilterdiffneutral / info / success / warning / danger
Used in KaziLayer
Lifecycle, contract, job, webhook, notification and SLA states.
View all 4 variants →10
Field/multiselect
HVAC ×Priority ×
Variants and states
viewinputfilterdiff
Used in KaziLayer
Tags, event scopes, permissions and multi-value configuration.
View all 5 variants →11
Field/relation
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Tenant-scoped customer, site, asset, technician, user and role relationships.
View all 5 variants →12
Field/integer
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Counts, capacity, order, weight and numeric limits.
View all 5 variants →13
Field/decimal
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Scores, percentages and precision-sensitive decimal configuration.
View all 5 variants →14
Field/boolean
Evidence required
Variants and states
viewinputfilterdiff
Used in KaziLayer
Required, enabled, preference and policy toggles.
View all 5 variants →15
Field/date
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Date-only contract, settings and reporting fields.
View all 5 variants →16
Field/datetime
Contract validation and help appear here.
Variants and states
viewinputfilterdiff
Used in KaziLayer
Windows, schedules, deadlines, publication and event timestamps.
View all 5 variants →17
Field/relative-time
05 Oct 2026 · 14:22 EAT
Variants and states
viewlive relative labelaccessible absolute timestamp
Used in KaziLayer
Updated-at values, activity events and notifications.
View all 3 variants →18
Field/file
DOC.02
Variants and states
viewinputuploading / scanning / ready / rejected / error
Used in KaziLayer
Documents, CSV imports, exports and work evidence.
View all 3 variants →19
Field/image
DOC.02
Variants and states
thumb / coverinputuploading / processing / ready / error
Used in KaziLayer
Image evidence, feedback screenshots and previewable media.
View all 3 variants →20
Field/url
Contract validation and help appear here.
Variants and states
viewinputfiltervalid / invalid / disabled
Used in KaziLayer
Webhook endpoints, documentation links and integration URLs.
View all 4 variants →21
Field/code
work_order.scheduled
Variants and states
viewinputdiffcopyable / read-only / invalid format
Used in KaziLayer
References, event keys, contract keys, paths and machine identifiers.
View all 4 variants →22
Field/location
Contract validation and help appear here.
Variants and states
viewinputfilterlocating / geocode error / privacy restriction
Used in KaziLayer
Request and site location capture and map-picker surfaces.
View all 4 variants →23
Field/timezone
Contract validation and help appear here.
Variants and states
viewinputfilterselected / searching / invalid
Used in KaziLayer
Organisation, calendar and SLA policy settings.
View all 4 variants →Dynamic component type 03
KaziLayer configured and divergent components
Specialised operations interactions reuse kernel fields, recipes, actions and feedback.
01
SavedViewToolbar
Metric / Trend
Alert
List
SavedViewToolbar
Variants and states
scope: list / dispatch / dashboarddefault / dirty / savedcompact / comfortable
Used in KaziLayer
Saves filters, sorts, columns, density and dashboard selections.
View all 3 variants →02
CommentThreadBlock
AKBMLW+4
Amina added completion evidence.
Variants and states
internal / customercompact / comfortableattachments on / offmentions on / off
Used in KaziLayer
Request and work-order details plus approved customer discussion.
View all 4 variants →03
EvidenceGalleryBlock
DOC.02
Variants and states
grid / list / previewimage / document / mixeduploading / scanning / ready / restricted / error
Used in KaziLayer
Evidence capture, completion review, audit and approved customer views.
View all 3 variants →04
ConflictResolutionSheet
Local14:00
→Server15:30
Variants and states
reload / compare / mergeFieldDiff by widgetwarning / danger
Used in KaziLayer
Stale edit and transition recovery with server-versus-local values.
View all 3 variants →05
ContractVersionList
Fields
Workflow
Policy
ContractVersionListDraft
Variants and states
draft / published / retiredcompactbordered / flat
Used in KaziLayer
Contract registry pages and publication history.
View all 3 variants →06
ContractBuilderBlock
Fields
Workflow
Policy
ContractBuilderBlockDraft
Variants and states
fields / validation / workflow / presentation / policiesdraft / reviewvalid / invalid / dirty / publishing
Used in KaziLayer
Creates contract metadata without hard-coded model-specific forms.
View all 3 variants →07
FieldDefinitionEditor
Fields
Workflow
Policy
FieldDefinitionEditorDraft
Variants and states
widget editorrequired / read-only / filterable / orderablegroup / weight / role
Used in KaziLayer
Edits contract fields and presentation metadata.
View all 3 variants →08
WorkflowTransitionEditor
Fields
Workflow
Policy
WorkflowTransitionEditorDraft
Variants and states
state-nodetransition-edgeguardsrequired evidence
Used in KaziLayer
Administers work-lifecycle contracts.
View all 5 variants →09
PolicyMatrixEditor
Fields
Workflow
Policy
PolicyMatrixEditorDraft
Variants and states
role × action / fieldread / write visibilityallow / deny / restricted
Used in KaziLayer
Administers role policy and field-level contract policy.
View all 3 variants →10
DispatchBoardBlock
Amina
Brian
Linet
Variants and states
board / timelinecompact / comfortablepointer / keyboardloading / live / conflict / stale
Used in KaziLayer
Coordinates unscheduled work, capacity, assignment and rescheduling.
View all 4 variants →11
TechnicianCapacityLane
Amina
Brian
Linet
Variants and states
available / limited / unavailableneutral / info / warning / danger
Used in KaziLayer
Shows technician capacity inside the dispatch board.
View all 2 variants →12
ScheduleEditorSheet
Amina
Brian
Linet
Variants and states
assign / reschedulefixed / rangevalid / conflict / saving / error
Used in KaziLayer
Runs schedule commands from dispatch and work-order detail.
View all 3 variants →13
SlaIndicator
Amina
Brian
Linet
Variants and states
safe / at-risk / breached / paused / completedcompact / full
Used in KaziLayer
Appears in rows, cards, detail, dashboard alerts and dispatch.
View all 2 variants →14
DashboardComposerBlock
Metric / Trend
Alert
List
DashboardComposerBlock
Variants and states
view / edit1 / 2 / 3 columnsclean / dirty / saving
Used in KaziLayer
Lets managers compose dashboards from shared metric recipes.
View all 3 variants →15
MetricWidget
SLA within target93.4%
+2.8%Variants and states
metric / trend / distribution / table / alerttonesurface
Used in KaziLayer
Keeps card, chart, export and API output aligned to one metric definition.
View all 3 variants →16
ImportWizard
ImportWizard72%
VALIDATEPROCESSCOMPLETE
Variants and states
upload / map / validate / preview / commit / resultsvalid / invalid / running / partial-failure / done
Used in KaziLayer
Guides validated administrative CSV imports.
View all 2 variants →17
ExportJobPanel
ExportJobPanel72%
VALIDATEPROCESSCOMPLETE
Variants and states
queued / running / complete / failed / expiredCSV / allowed formats
Used in KaziLayer
Tracks bounded asynchronous export jobs.
View all 2 variants →18
WebhookEndpointPanel
WebhookEndpointPanel72%
VALIDATEPROCESSCOMPLETE
Variants and states
create / edit / rotate-secretactive / disabled / error
Used in KaziLayer
Configures signed integration endpoints and secret rotation.
View all 2 variants →19
WebhookDeliveryLogBlock
WebhookDeliveryLogBlock72%
VALIDATEPROCESSCOMPLETE
Variants and states
delivered / retrying / failedcompactpayload collapsed / expanded
Used in KaziLayer
Supports webhook delivery troubleshooting and audit review.
View all 3 variants →20
NotificationCenter
AKBMLW+4
Amina added completion evidence.
Variants and states
unread / allin-app / emailunread / read / failed
Used in KaziLayer
Provides the authenticated notification surface and preference links.
View all 3 variants →21
FeedbackCaptureSheet
Reduced motion
High contrast
Compact density
Variants and states
screenshot none / attachedconsent off / onediting / submitting / sent / error
Used in KaziLayer
Collects contextual, consent-aware user feedback.
View all 3 variants →22
AccessibilityPreferencesPanel
Reduced motion
High contrast
Compact density
Variants and states
compact / comfortable / spaciousreduced motioncontrastinput preferences
Used in KaziLayer
Applies presentation preferences without mutating domain data.
View all 4 variants →Dynamic component type 04
Divergent marketing and public storytelling
Hand-written storytelling components reuse the same tokens, primitives and accessibility policies.
01
MarketingHeader
KAZILAYEROperations/Marketing Header
Variants and states
publicstickymobile-menu
Used in KaziLayer
Landing and public product routes.
View all 3 variants →02
SystemicPrecisionHero
SYSTEMICPRECISIONHEROOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
defaultcompactmotion normal / reduced
Used in KaziLayer
Landing hero communicating operational control and the layer-flow metaphor.
View all 3 variants →03
LayerFlowVisualization
LAYERFLOWVISUALIZATIONOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
animatedstaticreduced-motion
Used in KaziLayer
Explains request → dispatch → field work → audit.
View all 3 variants →04
ModuleFeatureGrid
MODULEFEATUREGRIDOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
2-column4-columnstacked
Used in KaziLayer
Introduces requests, dispatch, field work and audit modules.
View all 3 variants →05
AdaptiveProjectionDemo
ADAPTIVEPROJECTIONDEMOOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
formtablecardtimeline
Used in KaziLayer
Shows one record adapting into several contract-driven views.
View all 5 variants →06
RoleOutcomeTabs
ROLEOUTCOMETABSOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
ownerdispatchertechniciancustomer
Used in KaziLayer
Explains role-specific outcomes on the landing page.
View all 5 variants →07
PerformanceProofStrip
SLA within target93.4%
+2.8%Variants and states
metricsbenchmarkscompact
Used in KaziLayer
Shows Web Vitals, API, concurrency and test evidence.
View all 3 variants →08
ArchitectureTraceabilityPanel
ARCHITECTURETRACEABILITYPANELOne operational truth.
Every role in flow.
Every role in flow.
Variants and states
collapsedexpanded
Used in KaziLayer
Links contract, API/event, UI, audit and test evidence.
View all 2 variants →
